Intelligent Special Machine
RSIT— A drafter of multiple national and industry standards, with 20 years of proven experience, delivers highly customized intelligent solutions for the apparel industry, backed by a dual guarantee of quality and reputation, empowering enterprises in smart manufacturing transformation.
Intelligent stacker crane warehouse
Fully automatic cleaning of adhered thread ends, lint, floating dust and static electricity on the product surface.
Fully automatic dryer
When used in conjunction with the intelligent hanging system, it can dry all the clothes passing through the dryer without changing the clothes rack, and can be used as a substitute for a drying room.
Fully automatic feeding machine
The collar shape is uniform, the fabric holding effect is obvious, the product qualityis high,the skillis removed,the automatic bone position is found, and the automatic sewing quality is stable and efficient.
Intelligent stacker crane warehouse
Compatible with intelligent suspension systems.Self-developed patented technology On average.
3 to 7 labor costs are saved.
Green and sustainable.
| Equipment Intro duction | 1.35*0.87*1.52mm |
|---|---|
| Applicable height | Applicable to standard intelligent hanging processing areas, 1.4 meters -1.45 meters above the ground (customizable) |
| Applicable width | Station width 1.68 meters |
| Voltage | 380V |
| Air pressurer | 0.4MPa—0.7MPa |
| Power | 3.7KW |
| Noise | 50dB |
| Cleaning effect | 95-98% surface cleaning rate |
| Production efficiency | 10 to 13 seconds per piece, 2,500 to 3,600 pieces per person per 10 hours |
| Clothing types | Garments, hats and clothes, fabric dolls, etc |
Fully automatic dryer
Seamless production collaboration.Dynamic beat matching.
Steam permeation technology.
Energy closed-loop design.
| Power | 6KW |
|---|---|
| Voltage | 380V |
| Weight | 2T |
| Dimensions | 8500*1500*2200(Height can be customized according to the height of the main l ine) |
| Steam consumption | 1-1.5 tons per day |
| Efficiency | 20 seconds per piece, 30,000 pieces per day |
| Drying effect | The surface humidity can be dried to 20%RH from 60%RH to 80%RH |
| Types of dried clothing | All categories |
Fully automatic feeding machine
Precise craftsmanship and zero-defect quality control.convenient order turnover production.
High-speed continuous operation Intelligent model change and code adjustment.
Standardized production.
| Needle model | DCx1(11#) |
|---|---|
| Sewing speed | 0-rpm |
| Nstitch length | 12mm-5mm |
| Power | 1.0kW |
| Voltage information | 220V 50Hz |
| Air pressure | 0.6MPa |
| Nweight | 200kg |
| Functional efficiency | Automatic pick-up in 20 seconds, skilled worker in 60 seconds |
| Scope of application | The upper T-shirt has a round neck, with a width range of 12-38mm and a circumference range of 450-770mm |
| Compatible models | Jack 797T, Pegasus EX5100, Daiwa AZF8400, Kansai JT5014 |
